| Place of Origin: | Beijing, China |
|---|---|
| Brand Name: | XFusion |
| Model Number: | 2288H v5 |
| Minimum Order Quantity: | 1 unit |
| Price: | $950.00/pieces 1-9 pieces |
| Private Mold: | NO | Products Status: | Stock |
|---|---|---|---|
| Type: | Rack | Processor Type: | Intel Xeon |
Item | XFusion 2288H V5 Intel Xeon CPU PC Computer 2u Rack Server |
Brand | XFusion |
Type | 2U Dual Socket Rack Server |
Processor | 1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205 W 1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205 W |
Memory | 24 DDR4 DIMM slots, 2933 MT/s; up to 12 Intel® Optane™ PMem modules (100 series), 2666 MT/s |
Storage Controllers | RAID 0, 1, 1E, 5, 50, 6, or 60; optional supercapacitor for cache power-off protection; RAID-level migration, drive roaming, self-diagnosis, and web-based remote configuration |
Drive Bays | Supports hot-swappable hard drives with the following configuration options: • 8/20/24/25/31 x 2.5-inch SAS/SATA/SSD hard drives •12/16/20 x 3.5-inch SAS/SATA hard drives • 4/8/12/24/28 NVMe SSDs Flash storage: • 2 M.2 SSDs |
Power Supply | 2 hot-swappable PSUs with support for 1+1 redundancy and the following configuration options: • 550 W AC Platinum PSUs (input:100V to 240 VAC, or 192 V to 288 V DC) • 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC) • 1500 W AC Platinum PSUs • 1000 W (input: 100 V to 127 V AC) • 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC) • 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC) • 1200 W -48 V to -60 V DC PSUs (input: -38.4 V to -72 V DC) |
