| Place of Origin: | Fujian, China |
|---|---|
| Brand Name: | H3C |
| Model Number: | H3C S5720-32X-EI-24S-DC switch |
| Minimum Order Quantity: | 1 unit |
| Price: | $1,000.00/pieces 1-9 pieces |
| Private Mold: | NO | Products Status: | Stock, Used, Stock |
|---|---|---|---|
| Ports: | ≥ 48 | Transmission Rate: | 10/100/1000Mbps |
| Function: | LACP, SNMP | Communication Mode: | Full-Duplex & Half-Duplex |
| Switch Capacity: | 56 Gb/s | Product Name: | H3C S5720-32X-EI-24S-DC Switch |
| Type: | Rack |
Huawei S5720-32X-EI-24S-DC Switch is an Enhanced Gigabit Switch with 24 Gig SFP, 4 Ethernet 10/100/1000 ports, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports and AC or DC power supply, supporting RPS, power socket on the front panel
The switch offers lexible GE access ports (including optical, electrical, and combo ports) and 10GE uplink ports. Built on next-generation high-performance processors and Huawei Versatile Routing Platform (VRP), Huawei S5720-32X-EI-24S-DC provides larger table sizes and higher hardware processing capabilities than equivalent switches. Additionally, it provides comprehensive service processing capabilities, enhanced security control, and mature IPv6 features, and supports MACsec, intelligent stack (iStack), flexible Ethernet networking, and easy operations and maintenance (O&M). Moreover, S5720-EI supports Super Virtual Fabric (SVF), which virtualizes the “Core/aggregation + Access switch + AP” structure into a logical device. S5720-EI enables the simplest network management solution in the industry. It allows plug-and-play access switches and APs. S5720-EI also supports service configuration templates. The templates are configured on core devices and automatically delivered to access devices, enabling centralized control, simplified service configuration, and flexible configuration modification. The S5720-EI functions as a client in an SVF system.
| Item | Description |
| Model | S5720-32X-EI-24S-DC |
| Part number | 02350NHE |
| Port | 24 Gig SFP, 4 Ethernet 10/100/1000 ports, 4 10 Gig SFP+, 2 QSFP+ dedicated stack ports AC or DC power supply, supporting RPS, power socket on the front panel |
| Memory (RAM) | 2 GB |
| Flash | 512 MB in total. To view the available flash memory size, run the display version command. |
| Mean time between failures (MTBF) | 82.54 years |
| Mean time to repair (MTTR) | 2 hours |
| Availability | > 0.99999 |
| Service port surge protection | Common mode: ±6 kV |
| Power supply surge protection | ±1 kV in differential mode, ±2 kV in common mode |
| Weight (with packaging) | 4.2 kg (9.26 lb) |
| Stack ports | Two fixed QSFP+ stack ports on the rear card |
| Rated voltage range | -48 V DC to -60 V DC |
| Maximum voltage range | -36 V DC to -72 V DC |
| Maximum power consumption (100% throughput, full speed of fans) | 58.9 W |
| Operating temperature | 0°C to 45°C (32°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Storage temperature | -40°C to +70°C (-40°F to +158°F) |
| Noise under normal temperature (27°C, sound power) | < 49.3 dB(A) |
| Relative humidity | 5% to 95%, noncondensing |
| Operating altitude | 0-2000 m (0-6562 ft.) |
| Certification | EMC certification |
| Safety certification | |
| Manufacturing certification | |
| Dimensions (H x W x D) | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 224.9 mm (1.72 in. x 17.4 in. x 8.85 in.) |
| Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 237.3 mm (1.72 in. x 17.4 in. x 9.34 in.) |
