| Place of Origin: | Fujian, China |
|---|---|
| Brand Name: | H3C |
| Model Number: | H3C S5720-52p-Si-AC Switch |
| Minimum Order Quantity: | 1 unit |
| Price: | $1,300.00/pieces 1-9 pieces |
| Private Mold: | NO | Products Status: | Stock, Used, Stock |
|---|---|---|---|
| Ports: | ≥ 48 | Transmission Rate: | 10/100/1000Mbps |
| Function: | LACP, SNMP | Communication Mode: | Full-Duplex & Half-Duplex |
| Switch Capacity: | 56 Gb/s | Product Name: | H3C S5720-52p-Si-AC Switch |
| Type: | Rack |
|
Item
|
H3C S5720-52p-Si-AC Switch
|
|
Packet forwarding rate
|
96Mpps
|
|
exchange capacity
|
336Gbps/3.024Tbps
|
|
Fixed port
|
48 10/100/1000Base-T, 4 Gigabit SFPs
|
|
Network standards
|
IEEE 802.3,IEEE 802.3u,IEEE 802.3ab,IEEE 802.3z,IEEE 802.3x,IEEE 802.1Q,IEEE 802.1d,IEEE 802.1X
|
|
VLAN
|
Supports 4K VLANs Supports Guest VLAN and Voice VLAN Support VLAN based on MAC/protocol/IP subnet/policy/port Supports 1:1 and N:
1 VLAN switching functionality Supports SuperVLAN |
|
QOS
|
Support limiting the speed of receiving and sending packets on the port Support packet redirection Supports port based traffic
monitoring and dual speed three color CAR function Supports 8 queues per port Support WRR, DRR, SP, WRR+SP, DRR+SP queue scheduling algorithms Supports re labeling of 802.1p and DSCP priority for messages Supports L2 (Layer 2) - L4 (Layer 4) packet filtering function, providing source MAC based filtering Address, destination MAC address, source IP address, destination IP address, port, protocol, VLAN Illegal frame filtering function of Supports queue based speed limit and traffic shaping functions |
|
security management
|
User classification management and password protection Support for preventing DOS, ARP attacks, and ICMP attacks Supports
combination binding of IP, MAC, port, and VLAN Supports port isolation, port security, and Sticky MAC Supports black hole MAC addresses Support MAC address learning limit Supports IEEE 802.1X authentication and supports maximum single port user limit Supports AAA certification, supports multiple methods such as radius, TACACS+, NAC, etc Support SSH V2.0 Supports HTTPS Support CPU protection function Support blacklist and whitelist |
