| Place of Origin: | Fujian, China |
|---|---|
| Brand Name: | H3C |
| Model Number: | H3C S5730-68c-Hi Switch |
| Minimum Order Quantity: | 1 unit |
| Price: | $1,300.00/pieces 1-9 pieces |
| Private Mold: | NO | Products Status: | Stock, Used, Stock |
|---|---|---|---|
| Ports: | ≥ 48 | Transmission Rate: | 10/100/1000Mbps |
| Function: | LACP, SNMP | Communication Mode: | Full-Duplex & Half-Duplex |
| Switch Capacity: | 56 Gb/s | Product Name: | H3C S5730-68c-Hi Switch |
| Type: | Rack |
|
Item
|
H3C S5730-68c-Hi Switch
|
|
Memory (RAM)
|
2 GB
|
|
Flash
|
1 GB in total. To view the available flash memory size, run the display version command.
|
|
Mean time between failures (MTBF)
|
49.29 years
|
|
Mean time to repair (MTTR)
|
2 hours
|
|
Availability
|
> 0.99999
|
|
Service port surge protection
|
Common mode: ±7 kV
|
|
Power supply surge protection
|
* Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode
* Using DC power modules: ±1 kV in differential mode, ±2 kV in common mode |
|
Dimensions (H x W x D)
|
* Basic dimensions (excluding the parts protruding from the body): 44.4 mm x 442.0 mm x 424.7 mm (1.75 in. x 17.4 in. x 16.72
in.) * Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 44.4 mm x 442.0 mm x 451.8 mm (1.75 in. x 17.4 in. x 17.79 in.) |
|
Weight (with packaging)
|
8.5 kg (18.74 lb)
|
|
Stack ports
|
10GE SFP+ ports on the front panel, or 10GE ports or 40GE QSFP+ ports on the rear card
|
|
RTC
|
Supported
|
|
RPS
|
Not supported
|
|
PoE
|
Not supported
|
|
Rated voltage range
|
100 V AC to 240 V AC, 50/60 Hz
-48 V DC to -60 V DC |
|
Maximum voltage range
|
90 V AC to 264 V AC, 47 Hz to 63 Hz
-36 V DC to -72 V DC |
|
Maximum power consumption (100% throughput, full speed of fans)
|
88.05 W (without card)
|
