| Place of Origin: | Fujian, China |
|---|---|
| Brand Name: | H3C |
| Model Number: | H3C S6720-30c-Ei-24s-DC Switch |
| Minimum Order Quantity: | 1 unit |
| Price: | $1,300.00/pieces 1-9 pieces |
| Private Mold: | NO | Products Status: | Stock, Used, Stock |
|---|---|---|---|
| Ports: | ≥ 48 | Transmission Rate: | 10/100/1000Mbps |
| Function: | LACP, SNMP | Communication Mode: | Full-Duplex & Half-Duplex |
| Switch Capacity: | 56 Gb/s | Product Name: | H3C S6720-30c-Ei-24s-DC Switch |
| Type: | Rack |
|
Item
|
H3C S6720-30c-Ei-24s-DC Switch
|
|
Memory (RAM)
|
2 GB
|
|
Flash
|
512 MB in total. To view the available flash memory size, run the display version command.
|
|
Mean time between failures (MTBF)
|
80.60 years when no interface card is configured; 70.79 years when a 4-port 40GE interface card is configured
|
|
Mean time to repair (MTTR)
|
2 hours
|
|
Availability
|
> 0.99999
|
|
Service port surge protection
|
NA
|
|
Power supply surge protection
|
* Using AC power modules: ±6 kV in differential mode, ±6 kV in common mode
* Using DC power modules: ±1 kV in differential mode, ±2 kV in common mode |
|
Dimensions (W x D x H)
|
442.0 mm x 420.0 mm x 44.4 mm (17.4 in. x 16.5 in. x 1.74 in.)
|
|
Weight (including packaging materials)
|
9.8 kg (21.61 lb)
|
|
Stack ports
|
* Any 10GE SFP+ ports on the front panel (a maximum of 16 physical ports)
* Any 40GE QSFP+ ports (a maximum of 6 physical ports) |
|
RTC
|
Supported
|
|
RPS
|
Not supported
|
|
PoE
|
Not supported
|
|
Rated voltage range
|
100 V AC to 240 V AC, 50/60 Hz
-48 V DC to -60 V DC |
|
Maximum voltage range
|
90 V AC to 264 V AC, 47 Hz to 63 Hz
-38.4 V DC to -72 V DC |
|
Maximum power consumption (100% throughput, full speed of fans)
|
212.5 W
|
|
Typical power consumption (30% of traffic load) * Tested according to ATIS standard
* EEE enabled * No PoE power consumption |
50.1 W (without card)
|
