| Place of Origin: | Fujian, China |
|---|---|
| Brand Name: | H3C |
| Model Number: | H3C S6720-54c-Ei-48s-DC Switch |
| Minimum Order Quantity: | 1 unit |
| Price: | $1,300.00/pieces 1-9 pieces |
| Delivery Time: | 3-5 days |
| Private Mold: | NO | Products Status: | Stock, Used, Stock |
|---|---|---|---|
| Ports: | ≥ 48 | Transmission Rate: | 10/100/1000Mbps |
| Function: | LACP, SNMP | Communication Mode: | Full-Duplex & Half-Duplex |
| Switch Capacity: | 56 Gb/s | Product Name: | H3C S6720-54c-Ei-48s-DC Switch |
| Type: | Rack |
Item | H3C S6720-54c-Ei-48s-DC Switch | ||||
Wide [mm] | 442.0 mm | ||||
Depth [mm] | 424.7 mm | ||||
Height [mm] | 44.4 mm | ||||
Chassis height [U] | 1 | ||||
Weight with packaging [kg(lb)] | 10.2 | ||||
Typical power consumption [W] | 185 | ||||
Maximum power consumption [W] | 268.6 | ||||
Typical heat dissipation [BTU/hour] | 631.24 | ||||
Maximum heat dissipation [BTU/hour] | 916.49 | ||||
Heat dissipation mode | Heat dissipation with fan, intelligent fan speed adjustment | ||||
Power supply mode | Pluggable power supply | ||||
Rated input voltage [V] | - AC input: 100 V AC to 240 V AC; 50/60 Hz - DC input: –48 V DC to –60 V DC | ||||
Input voltage range [V] | - AC input: 90 V AC to 264 V AC; 47 Hz to 63 Hz - DC input: -38.4 V DC to -72 V DC | ||||
Maximum input current [A] | The current specifications depend on the pluggable power modules in use. For details, see the related power module specifications. | ||||
Number of card slots | 1 | ||||
Number of power slots | 2 | ||||
Memory | 2 GB | ||||
Flash memory | 512 MB in total. To view the available flash memory size, run the display version command. | ||||
Redundant power supply | 1+1 Pluggable AC and DC power modules can be used together in the same switch. | ||||
Types of fans | Pluggable | ||||
Noise at normal temperature (acoustic pressure) [dB(A)] | 59.3 | ||||
Noise at normal temperature (acoustic power) [dB(A)] | 72.1 | ||||
Airflow direction | Air intake from left,front and right, air exhaustion from behind | ||||
Long-term operating temperature [°C(°F)] | 0°C to 45°C (32°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) | ||||
Storage temperature [°C(°F)] | -40°C to +70°C (-40°F to +158°F) | ||||
