| Place of Origin: | Fujian, China |
|---|---|
| Brand Name: | H3C |
| Model Number: | H3C Switch S6720-30L-Hi-24s |
| Minimum Order Quantity: | 1 unit |
| Price: | $1,300.00/pieces 1-9 pieces |
| Private Mold: | NO | Products Status: | Stock, Used, Stock |
|---|---|---|---|
| Ports: | ≥ 48 | Transmission Rate: | 10/100/1000Mbps |
| Function: | LACP, SNMP | Communication Mode: | Full-Duplex & Half-Duplex |
| Switch Capacity: | 56 Gb/s | Product Name: | H3C Switch S6720-30L-Hi-24s |
| Type: | Rack |
|
Item
|
H3C Switch S6720-30L-Hi-24s
|
|
|
Specification
|
|
|
|
Fixed port
|
24 x 10 Gig SFP+, 4 x 40 Gig QSFP+, 2 x 100 Gig QSFP28
|
|
|
MAC address table
|
64K MAC address entries
IEEE 802.1d standards compliance MAC address learning and aging Static, dynamic, and blackhole MAC address entries Packet filtering based on source MAC addresses |
|
|
VLAN
|
4K VLANs
Guest VLANs and voice VLANs GVRP MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports VLAN mapping |
|
|
IP routing
|
Static routes, RIP v1/2, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, ECMP, routing policy
|
|
|
Interoperability
|
VLAN-Based Spanning Tree (VBST), working with PVST, PVST+, and RPVST
Link-type Negotiation Protocol (LNP), similar to DTP VLAN Central Management Protocol (VCMP), similar to VTP |
|
|
Wireless Service
|
AP access control, AP domain management, and AP configuration template management
Radio management, unified static configuration, and dynamic centralized management WLAN basic services, QoS, security, and user management CAPWAP, tag/terminal location, and spectrum analysis |
|
|
Ethernet Loop Protection
|
RRPP ring topology and RRPP multi-instance
Smart Link tree topology and Smart Link multi-instance, providing millisecond-level protection switchover SEP ERPS (G.8032) BFD for OSPF, BFD for IS-IS, BFD for VRRP, and BFD for PIM STP (IEEE 802.1d), RSTP (IEEE 802.1w), and MSTP (IEEE 802.1s) BPDU protection, root protection, and loop protection |
|
|
MPLS
|
MPLS L3VPN
MPLS L2VPN (VPWS/VPLS) MPLS-TE MPLS QoS |
|
|
IPv6 Features
|
Neighbor Discover (ND)
PMTU IPv6 Ping, IPv6 Tracert, IPv6 Telnet ACLs based on source IPv6 addresses, destination IPv6 addresses, Layer 4 ports, or protocol types Multicast Listener Discovery snooping (MLDv1/v2) IPv6 addresses configured for sub-interfaces, VRRP6, DHCPv6, and L3VPN |
|
|
Multicast
|
IGMP v1/v2/v3 snooping and IGMP fast leave
Multicast forwarding in a VLAN and multicast replication between VLANs Multicast load balancing among member ports of a trunk Controllable multicast Port-based multicast traffic statistics IGMP v1/v2/v3, PIM-SM, PIM-DM, and PIM-SSM MSDP Multicast VPN |
|
|
RPS
|
Not supported
|
|
|
PoE
|
Supported
|
|
|
Rated voltage range
|
100 V AC to 240 V AC, 50/60 Hz
-48 V DC to -60 V DC |
|
|
Maximum voltage range
|
90 V AC to 264 V AC, 47 Hz to 63 Hz
-38.4 V DC to -72 V DC |
|
|
Maximum power consumption (100% throughput, full speed of fans)
|
* Not providing the PoE function: 68.3 W (without card)
* 100% PoE loads: 925 W (system power consumption: 185.8 W, PoE: 739.2 W, without card) |
|
|
Typical power consumption (30% of traffic load) * Tested according to ATIS standard
* EEE enabled * No PoE power consumption |
50.1 W (without card)
|
|
